Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | 19" Rackmount, Wall, DIN-Rail mount |
| Type | Fans |
CPU | |
| Processor Installed | Intel Core i5-6500TE |
| Max CPU frequency | 3.3 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Realtek RTL8111G-CG 10/100/1000Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 3 |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | HDMI, 2xRJ45 Ethernet, 8xUSB, Mic In, Line Out, DC Input, Display Port |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Dimensions and weight | |
| Width | 250 mm |
| Height | 44.2 mm |
| Depth | 225 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
| Vibration | 1 Grms (HDD x 1); 3 Grms (SSD x 1) |
Standards and Certifications | |
| Certifications | CE |
