CPU | |
| СPU Generation/Family | Comet Lake |
| Socket | LGA1200 |
Chipset | |
| Chipset | Intel W480E |
Memory | |
| Socket Type | 4xDDR4 DIMM 288pin |
| ECC | Yes |
| Maximum Memory | 128 GB |
Graphic | |
| Interfaces | DisplayPort, LVDS, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM, Intel X550-AT2, Intel i225LM |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 6 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 13 |
| USB 2.0 | 7 |
Audio | |
| Audio Controller | Realtek ALC888 |
Extension Slots | |
| Total | 4 |
| PCI Express x16 | 2 |
| PCI Express x8 | 2 |
| PCI Express x4 | 2 |
| M.2 | 1 |
Connectors | |
| Connectors | DB9, DB15 VGA, LVDS, HDMI, 3xUSB, 10xUSB, Audio, Display Port, 6xRJ45, DB15 GPIO |
Dimensions and weight | |
| Width | 243.84 mm |
| Length | 243.84 mm |
