Power Supply |
| Type of Power Supply | Direct current |
| Output Power | 25 W |
| Output Voltage DC | 48 V |
| Rated current | 0.52 A |
| AC input voltage | 100-220 V |
Construction |
| Mounting Configuration | Desktop |
Connectors |
| Connectors | Pin Header |
Dimensions and weight |
| Width | 74 mm |
| Depth | 52 mm |
| Height | 109 mm |
Operating Conditions |
| Operating Temperature | 0...50 °C |
| Humidity | 20-90% |
| MTBF | 50000 h |
| Temperature (Storage) | -40~+85 |
Standards and Certifications |
| EMI | en55032-cispr32_class_b, FCC Part 15, CISPR 22 Class, EN 61000-3-2 Class A, EN 61000-3-3 |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Safety | UL 62368-1, csa_c22.2_no._62368-1, en_62368_1 |
