ET-7083

Name: ET-7083
Brand: ICP DAS
SKU: 06405400
Availability: InStock

ICP DAS

Ціна за запитом

Digital Input Module with 3-ch Encoder/Counter Inputs, 3-Axis 32-bit

Специфікація

Specification

Construction
Construction Chassis	Plastic Chassis
Mounting Configuration	Wall, DIN-Rail mount
Ethernet
10/100 Mbit/s	1
Supported Protocols
Industrial Protocols	Modbus TCP server, Modbus UDP slave
Digital Input
Number of channels	3
Signal Type	CW/CCW, Pulse/Dir, Quadrant
Counter capacity	32 Bit
Max frequency	4 kHz
Additional Functions
Watchdog timer type	Hardware, Software
System Power Input
Input Voltage DC	10...30 V
Dimensions and weight
Width	72 mm
Depth	35 mm
Height	123 mm
Operating Conditions
Operating Temperature	-25...75 °C
Standards and Certifications
EMS	IEC 61000-4-2, IEC 61000-4-4

Документація
