Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Ethernet |
| 10/100 Mbit/s | 2 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Analog Input |
| Total channels of analog input | 8 |
| Number of Bits | 16 Bit |
| Voltage range | 0...500 mV, 0...1 V, 0...5 V, 0...10 V, 0...150 mV |
| Sampling rate | 10 Hz |
| Differential channels | 8 |
Digital Output |
| Total channels of digital output | 4 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~50 V |
| Max. load current | 700 mA |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 12...48 V |
Dimensions and weight |
| Width | 76 mm |
| Depth | 38 mm |
| Height | 120 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
