Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Display | |
| Display Type | LED Character |
Ethernet | |
| 10/100 Mbit/s | 1 |
Interfaces | |
| RS-232 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, Modbus UDP slave |
Digital Output | |
| Total channels of digital output | 24 |
| Type | Electromagnitic relay |
| Relay (Form A) | 18 |
| Contact rating of relay (Form A) | 5A@250V AC, 5A@28V DC |
| Relay (Form C) | 6 |
| Contact rating of relay (Form C) | 2A@30V DC, 2A@250V AC |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 180 mm |
| Depth | 111 mm |
| Height | 70 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
