Specification
Construction | |
| Construction Chassis | Plastic Chassis |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 16 Bit |
| Sampling rate | 8 Hz |
| Thermal resistance | Pt100, Pt1000, JPt100 |
Connectors | |
| Connectors | DB37 Male |
Dimensions and weight | |
| Width | 30 mm |
| Depth | 85 mm |
| Height | 115 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | IEC 61000-6-2, IEC 61000-6-4 |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
