Specification
Construction | |
| Construction Chassis | Plastic Chassis |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 16 Bit |
| Voltage range | +/-15 mV, +/-50 mV, +/-100 mV, +/-150 mV, +/-500 mV, +/-1 V, +/-2.5 V, +/-5 V, +/-10 V |
| Sampling rate | 8 Hz |
| Thermocouple | J: -210...+760 °С, K: -270...+1372 °С, T: -270...+400 °С, E: -270...+1000 °С, B: 0...1820 °С, N: -270...+1300 °С, C: 0...+2320 °С, R: -50...+1600 °С, S: -50...+1760 °С |
Connectors | |
| Connectors | DB37 Male |
Dimensions and weight | |
| Width | 30 mm |
| Depth | 85 mm |
| Height | 115 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | IEC 61000-6-2, IEC 61000-6-4 |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
