Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Processor Installed | Intel Core i5-1135G7 |
| Socket | FCBGA 1449 |
| Max CPU frequency | 4.2 GHz |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | HDMI |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 3 |
| USB 2.0 | 2 |
| USB v3.x | 1 |
Drive interfaces | |
| M.2 | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| Drive Interface | PCIe x4 |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2242 M, 2230 E |
LED / Controls | |
| LED | Power LED, SSD LED, LAN LED |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | M12 DC-in, 2xM12 LAN, M12 HDMI, 2x8-pin M12 USB, M12 USB, M12 |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows 11, Ubuntu |
Dimensions and weight | |
| Width | 260.4 mm |
| Height | 50.1 mm |
| Depth | 193 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Humidity | 10-90% |
| Vibration | 5Hz~500Hz / 1Grms / 3 axis |
| Shock | 15G. 11ms duration |
Standards and Certifications | |
| Certifications | CE/FCC |
