Construction | |
| Construction Chassis | Magnesium Alloy |
| Mounting Configuration | Wall VESA 100, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 12.1 " |
| Aspect Ratio | 4:3 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Qualcomm Snapdragon 660 |
Chipset | |
| Chipset | SoC |
Memory | |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 3 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 3 |
| USB 2.0 | 2 |
Industrial Interfaces | |
| CAN Port | 1 |
LED / Controls | |
| LED | Battеry Status, WLAN LED |
| Controls | On/Off, Function Keys |
Connectors | |
| Connectors | 3xDB9, RJ45 Ethernet, DC Input, SIM Card Slot, SD card slot, USB type C |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 84 W |
Software | |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 307 mm |
| Height | 225 mm |
| Depth | 41 mm |
Standards and Certifications | |
| Certifications | CE/FCC |
| EMS | EN 61000-4-2 |
| MIL-STD-810 | MIL-STD-810H Test Method 516.8 Shock, MIL-STD-810H Test Method 514.8 Vibration |
| Vandal Resistance | EN 62262, IK07 level |
