Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall VESA 100, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 14 " |
| Aspect Ratio | 16:9 |
| Brightness | 700 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Atom x6425E |
| Socket | CPU onboard |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Socket Type | 1xDDR4 SODIMM 260-pin |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 2 |
| USB 2.0 | 1 |
| USB v3.x | 1 |
Industrial Interfaces | |
| CAN Port | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, Function Keys |
Connectors | |
| Connectors | 2xDB9, RJ45 Ethernet, 1xUSB, DC Input, USB type C |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 84 W |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 342 mm |
| Height | 225 mm |
| Depth | 52 mm |
Operating Conditions | |
| Operating Temperature | -30...50 °C |
| Vibration | MILSTD810H Method 514.8 Procedure I |
| Shock | MILSTD810H Method 516.8 Procedure I |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
| Safety | UL 60950-1, EN 60950-1 |
