Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Wall, Wall VESA 100, Wall VESA 75 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-6300U |
Memory | |
| Socket Type | 2xSODIMM 260-pin |
| Maximum Memory | 32 GB |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
Extension Slots | |
| Total | 3 |
| PCI Express x1 | 1 |
Connectors | |
| Connectors | 4xDB9, HDMI, 2xRJ45 Ethernet, 4xUSB, DC Input, 2xDisplayPort, 2xSATA |
Software | |
| Operating System Compatibility | Windows 7, Linux OS, Windows 8.1, Windows 10 |
Dimensions and weight | |
| Width | 350 mm |
| Height | 274.5 mm |
| Depth | 87.5 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
