Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Panel, Wall, Wall VESA 75, Arm |
| Protection Level of Front Side (Panel) | IP65 |
| Material Front Side (Panel) | Aluminum |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 2000~1 |
| Input Interface | HDMI |
Touch Screen | |
| Touch Screen Type | Resistive |
| Interface | USB |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, KeyPad |
Connectors | |
| Connectors | HDMI, DC Input, USB type B |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | Industrial, External power adapter AC/DC |
| Output Power | 60 W |
| Input Voltage AC | 100...240 V |
| Input Voltage DC | 12...12 V |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | 5 ~ 500 Hz. 1 Grms (operating. random) |
Dimensions and weight | |
| Width | 392.3 mm |
| Height | 313.6 mm |
| Depth | 51.2 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CCC, UL |
