FPM-7151T-R3AE

Ціна за запитом
Industrial Embedded Monitor with 15" TFT LCD LED, IP65 for front panel, XGA 1024x768, resistive touch (RS-232 & USB), Anti-glare screen with tempered glass VGA, DP, aluminum front panel, power supply 24V DC

Specification

Construction

Construction ChassisStainless Steel
Mounting ConfigurationDesktop, Panel, Wall, Wall VESA 100, Wall VESA 75, Arm
Protection Level of Front Side (Panel)IP66
Material Front Side (Panel)Magnesium Alloy

Display

Display TypeLCD TFT
Diagonal15 "
Maximum resolution1024x768 Dots
Aspect Ratio4:3
Brightness400 Cd/m2
Contrast Ratio700~1
Input InterfaceDisplayPort, D-Sub

Touch Screen

Touch Screen TypeResistive
InterfaceRS-232, USB

LED / Controls

ControlsControl Buttons

Connectors

ConnectorsDB9, DB15 VGA, Display Port, Console Port USB, DC input (terminal block)

System Power Input

Input Voltage DC24...24 V
Power Consumption15 W

Operating Conditions

Operating Temperature-20...60 °C
Vibration5 ~ 500 Hz. 1 Grms

Dimensions and weight

Width383.2 mm
Height307.3 mm
Depth48.2 mm

Standards and Certifications

CertificationsCE, FCC Class A
SafetyCCC, UL, BSMI

Files

Documentation

📄 Datasheet FPM-7151T
