Ethernet |
| Total Ethernet | 8 |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 4 |
| Type 10/100/1000 Mbit/s | 4xRJ-45 |
Supported Protocols |
| Managment Protocols | SNTP, SNMPv1/v2c/v3, Telnet, NTP |
| Reservation protocols | STP, RSTP |
| Security Protocols | IEEE 802.1X Network Access Control, HTTPS, SSH, RADIUS, TACACS+ |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
LED / Controls |
| LED | Power LED, LAN LED |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
System Power Input |
| Input Voltage DC | 18...72 V |
| Input Voltage AC | 100...240 V |
Operating Conditions |
| Operating Temperature | 0...50 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop |
Dimensions and weight |
| Width | 168 mm |
| Depth | 220 mm |
| Height | 45 mm |
Standards and Certifications |
| Certifications | CE, FCC Class A |
