Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Height | 1 U |
| Type | Fan |
CPU | |
| Processor Installed | Intel Atom C2558 |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 2xDIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
Ethernet | |
| Total Ethernet | 7 |
| 10/100/1000 Mbit/s | 7 |
Extension Slots | |
| M.2 | 2 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | Mini-SIM |
LED / Controls | |
| LED | 1xHDD LED, Power LED, Level signal LED |
| Controls | On/Off |
Connectors | |
| Connectors | DC Input, USB type A, 7xRJ45 Ethernet, RJ45 (Console) |
System Power Input | |
| Input Voltage DC | 100...240 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 60 W |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 250 mm |
| Height | 44 mm |
| Depth | 190.4 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Vibration | with SSD: 0.3 Grms. IEC 60068-2-64. 5-500Hz. 1hr/axis |
| Shock | with SSD: 10G. IEC-60068-2-27. half sine. 11ms duration |
Standards and Certifications | |
| Certifications | CE |
| EMI | CCC (GB9254, GB 17625.1) |
