Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop |
| Height | 1 U |
| Type | Fan |
CPU | |
| Processor Installed | Intel Atom C2558 |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 2xDIMM |
| ECC | Yes |
| Maximum Memory | 16 GB |
Ethernet | |
| Controller Type | Intel i210 |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 6 |
Interfaces | |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | 6xRJ45 Ethernet, 2xUSB, DC Input, Console Port RS-232 (RJ-45) |
System Power Input | |
| Input Voltage DC | 100...240 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 280 mm |
| Height | 44 mm |
| Depth | 176 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Vibration | with HDD: 0.5 Grms. IEC 60068-2-64. 5-500Hz. 1hr/axis with SSD: 0.3 Grms. IEC 60068-2-64. 5-500Hz. 1hr/axis |
| Shock | with HDD/SSD: 10G. IEC-60068-2-27. half sine. 11ms duration |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| EMI | CCC (GB9254, GB 17625.1) |
