Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop |
| Height | 1 U |
| Type | Fan |
CPU | |
| Processor Installed | Intel Celeron J1900 |
| Max CPU frequency | 2.42 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 1 GB |
| Maximum Memory | 8 GB |
Graphic | |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces | |
| mSATA | 1 |
LED / Controls | |
| LED | 1xHDD LED, Power LED, LAN LED |
| Controls | On/Off |
Connectors | |
| Connectors | DB15 VGA, 4xRJ45 Ethernet, 2xUSB, DC Input, Console Port RS-232 (RJ-45) |
System Power Input | |
| Input Voltage DC | 100...240 V |
Power Supply | |
| Type of Power Supply | Open Frame |
| Output Power | 60 W |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 204 mm |
| Height | 44 mm |
| Depth | 178 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Vibration | with 2.5" HDD:0.5 Grms; IEC 60068-2-64; 5-500Hz.1hr/axis |
| Shock | with 2.5" HDD;10G. IEC-60068-2-27. half sine. 11 ms duration |
Standards and Certifications | |
| Certifications | CE |
| EMI | CCC (GB9254, GB 17625.1) |
