Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
| Type | Fans |
CPU | |
| Socket | LGA1151 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium, Xeon |
Chipset | |
| Chipset | Intel C236 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| ECC | Yes |
| Maximum Memory | 64 GB |
Graphic | |
| Interfaces | DVI, HDMI |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 6 |
Interfaces | |
| RS-232 | 1 |
| USB Total | 4 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
| CFast Slots | 1 |
| CompactFlash Slots | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 3.5" Cage Intenal | 2 |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
| Controls | On/Off |
Connectors | |
| Internal Ports | 2xUSB 3.0 |
| Connectors | DB15 VGA, 6xRJ45 Ethernet, 2xUSB, Console Port RS-232 (RJ-45) |
System Power Input | |
| Input Voltage AC | 100...240 V |
Power Supply | |
| Type of Power Supply | Redundant |
| Output Power | 300 W |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 438 mm |
| Height | 88 mm |
| Depth | 520 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | CCC (GB9254, GB 17625.1) |
