Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
| Type | Fan |
CPU | |
| Socket | LGA1155 |
| CPU Support Type | Core i5, Core i3, Pentium, Xeon, Celeron |
Chipset | |
| Chipset | Intel C226 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 4xDIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i210AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| mSATA | 1 |
| CFast Slots | 1 |
| CompactFlash Slots | 1 |
Storage Cage | |
| Number Of Cage External | 5 |
| 2.5" Cage External | 4 |
| 3.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 1 |
| PCI Express x8 | 1 |
LED / Controls | |
| LED | 1xHDD LED, 1xOn/Off LED |
| Controls | On/Off, Control Buttons |
| Setup of Operation Mode | Console Port, Buttons for Setting up and Displaying Status |
Connectors | |
| Connectors | DB15 VGA, 2xRJ45 Ethernet, 2xUSB, 2xAC Input, RJ45 (Console) |
System Power Input | |
| Input Voltage AC | 100...240 V |
Power Supply | |
| Type of Power Supply | Redundant, Internal |
| Output Power | 350 W |
| Quantity of Power Modules | 2 |
| Input Voltage AC | 100...240 V |
Software | |
| Operating System Compatibility | Windows 7, Linux OS |
Dimensions and weight | |
| Width | 430 mm |
| Height | 88 mm |
| Depth | 550 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Vibration | 0.5 Grms |
| Shock | 10G. 11ms |
