Specification
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | 80186 |
| Max CPU frequency | 0.08 GHz |
Installed drive | |
| Flash Memory Capacity | 0.512 MB |
| EEPROM Memory Capacity | 16 kB |
| Non-volatile NVRAM memory capacity | 31 Byte |
Drive interfaces | |
| MicroSD | 1 |
Software | |
| Operating System Installed | Mini OS7 |
| Programming Method | C/C++ |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 12 Bit |
| Current range | 0...20 mA |
Digital Input | |
| Total channels of digital input | 3 |
| Type | Dry contact, Wet contact |
| Sink/Source | Source |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 3.5~30 V |
Digital Output | |
| Total channels of digital output | 3 |
| Type | Open collector |
| Sink/Source | Sink |
| Max. load current | 100 mA |
| Output voltage | 1~30 V |
Ethernet | |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-485 | 1 |
Antenna characteristics | |
| Cellular interfaces | 2G, 3G |
Additional Functions | |
| Watchdog timer type | Hardware |
Dimensions and weight | |
| Width | 47 mm |
| Depth | 142 mm |
| Height | 168 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
