Construction | |
| Construction Chassis | ABS plastic chassis |
| Protection Level of Chassis | IP54 |
| Type | Fanless |
Display | |
| Display Type | LCD AFFS+TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 340 Cd/m2 |
| Contrast Ratio | 600~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Bay Trail |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| USB Total | 1 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
| SD Slots | 1 |
| MicroSDHC | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 32 GB |
Additional Functions | |
| Rear Camera | 5 MP |
| GPS | GPS |
| RFID Reader | Optional |
| MSR Reader | Optional |
| Smart Card Reader | Optional |
Antenna characteristics | |
| Bluetooth | v4.0 |
LED / Controls | |
| LED | Battеry Status, Power LED, WLAN LED, Bluetooth LED |
| Controls | On/Off, Control Buttons |
Connectors | |
| Connectors | 1xUSB, MicroSD card slot |
| Docking Station | Yes |
System Power Input | |
| Input Voltage DC | 19...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 2500 mA*h |
| RunTime Battery 1 | 8 h |
| Battery 1 Hotswap | Optional |
| Additional Battery Type | Li‑ion |
| Additional Battery Capacity | 1880 mA*h |
| Additional Battery Hotswap | No |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows Embedded 8.1 Industry, Ubuntu, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 294.1 mm |
| Height | 204.9 mm |
| Depth | 26.2 mm |
Operating Conditions | |
| Operating Temperature | -20...45 °C |
| Humidity | 10-95% |
| Vibration | 20 to 1000 Hz @ 1 grms per MIL-STD 810G (operating); 20 to 1000 Hz @ 3 grms per MIL-STD 810G (nonoperating) |
| Shock | 11 ms @ 20G per MIL-STD 810G for unit only (operating); 11 ms @ 40G per MIL-STD 810G for unit only (nonoperating) |
| Temperature (Storage) | -20~+60 |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | EN 55022 Class B |
| MIL-STD-810 | MIL-STD-810G Test Method 516.4 Drop 120 cm |
