Construction | |
| Construction Chassis | ABS plastic chassis |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 5.5 " |
| Maximum resolution | 1280x720 Dots |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex A7 |
| Max CPU frequency | 1 GHz |
Memory | |
| Default on Board Memory | 1 GB |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Interfaces | |
| USB Total | 1 |
Drive interfaces | |
| MicroSD | 1 |
| MicroSDHC | 1 |
Extension Slots | |
| SIM Card slots | 2, Yes |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
| GPS | GPS |
| MSR Reader | Optional |
| NFC | Yes |
| Sensors | G-sensor, Barometer, Gyroscope |
Antenna characteristics | |
| Cellular interfaces | 3G |
| Bluetooth | v4.0 + EDR |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | 1xMicro USB, MicroSD card slot, 2xSIM Card Slot |
System Power Input | |
| Input Voltage DC | 5...5 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 3600 mA*h |
| RunTime Battery 1 | 0 h |
Software | |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 84 mm |
| Height | 15.9 mm |
| Depth | 175.6 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
Standards and Certifications | |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
