Construction | |
| Construction Chassis | Rubber, Plastic Chassis |
| Protection Level of Chassis | IP54 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 1024x600 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 400~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Atom Z510 |
| Socket | CPU onboard |
| Max CPU frequency | 1.1 GHz |
Chipset | |
| Chipset | Intel US15W |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Intel GMA 500 |
Ethernet | |
| Controller Type | Realtek RTL8111 10/100/1000 Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces | |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | 2.5" |
| Drive Interface | IDE |
| 1st Storage Capacity | 32 GB |
| 2nd Storage Capacity | 4 GB |
Extension Slots | |
| SIM Card slots | Yes, 1 |
Additional Functions | |
| Camera Frontside | 1.3 MP |
| Rear Camera | 2 MP |
| RFID Reader | Yes |
Antenna characteristics | |
| Cellular interfaces | 3G (Optional) |
| Bluetooth | v2.1 + EDR |
LED / Controls | |
| LED | Power LED, 1xHDD LED, Battеry Status, Bluetooth LED, RFID LED |
| Controls | On/Off, 1xReset, Control Buttons |
Connectors | |
| Connectors | 2xUSB, DB9, RJ45 Ethernet |
| Docking Station | Yes |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 60 W |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 2600 mA*h |
| RunTime Battery 1 | 4 h |
Software | |
| Operating System Compatibility | Windows 7, Ubuntu, Fedora |
Dimensions and weight | |
| Width | 210 mm |
| Height | 160 mm |
| Depth | 36 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
| Humidity | 5-95% |
| Vibration | 1 Grms/ 5 ~ 500Hz/ random operation |
| Shock | 10G peak acceleration (11ms duration) |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
