Construction | |
| Construction Chassis | Metal Chassis, Rubber |
| Protection Level of Front Side (Panel) | IP67 |
| Protection Level of Chassis | IP67 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 5 " |
| Maximum resolution | 720x1280 Dots |
| Brightness | 500 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex-A53 |
| Socket | CPU onboard |
| Max CPU frequency | 1.3 GHz |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 2 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 16 GB |
Extension Slots | |
| SIM Card slots | Yes, 2, Micro-SIM |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 13 MP |
| GPS | GPS, GLONASS, Optional |
| NFC | Yes |
| Sensors | Light Sensor, Barometer, Gyroscope, Accelerometer, Proximity sensor |
Antenna characteristics | |
| Cellular interfaces | 4G, 3G |
| Bluetooth | v4.1 |
LED / Controls | |
| Controls | On/Off, Volume Keys |
Connectors | |
| Connectors | 2xSIM Card Slot, 1xMicro USB, MicroSD card slot |
System Power Input | |
| Input Voltage DC | 5...5 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 10 W |
| Supported Types of Power Supply | External power adapter AC/DC |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 4800 mA*h |
Software | |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 86 mm |
| Height | 165.8 mm |
| Depth | 25.6 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
| Humidity | 5-95% |
| Temperature (Storage) | -20~+60 |
