Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Maximum resolution | 1366x768 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 400 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Braswell |
| Processor Installed | Intel Pentium N3710 |
| Max CPU frequency | 2.56 GHz |
Chipset | |
| Chipset | Intel Braswell SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps, Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 1 |
LED / Controls | |
| LED | LED Bar |
| Controls | Control Buttons |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | HDMI, 2xRJ45 Ethernet, 4xUSB, Audio Out, DC input (terminal block), 2xDB9 Male |
System Power Input | |
| Input Voltage DC | 24...24 V |
| Power Consumption | 72 W |
Power Supply | |
| Supported Types of Power Supply | DC-DC |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 10 |
Dimensions and weight | |
| Width | 396.8 mm |
| Height | 247.1 mm |
| Depth | 59 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | 1G. 10 ~ 500 Hz. random for 2.5" SATA HDD |
Standards and Certifications | |
| Certifications | CE |
