Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP66, IP69K |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 350 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Braswell |
| Processor Installed | Intel Celeron N3060 |
| Max CPU frequency | 2.48 GHz |
Chipset | |
| Chipset | Intel Braswell SoC |
Memory | |
| Form-factor | DDR3L |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB 2.0 | 2 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Windows Embedded Standard 8, Windows 8.1, Windows 10 |
Dimensions and weight | |
| Width | 284 mm |
| Height | 241 mm |
| Depth | 56 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
| Vibration | 2G. 10 - 500Hz. random for SSD/mSATA |
