Ethernet | |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 24 |
| 10 Gbit SFP+ Ports | 4 |
Switch Properties | |
| Managed | Yes |
| Switch Level | Layer 2 |
Supported Protocols | |
| Managment Protocols | HTTP, RMON, Syslog, Telnet, QoS, IGMPv1/v2/v3, NTP, VLAN |
| Security Protocols | IP Address Filtering, IEEE 802.1X Network Access Control, SSH, RADIUS, TACACS+ |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.3ad for Port Trunk with LACP |
System Power Input | |
| Input Voltage DC | 36...60 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 1 U |
Dimensions and weight | |
| Width | 250 mm |
| Depth | 43.5 mm |
| Height | 440 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
