Specification
Power Supply | |
| Type of Power Supply | Direct current |
| Output Power | 60 W |
| Output Voltage DC | 24 V |
| Rated current | 2.5 A |
Construction | |
| Mounting Configuration | DIN-Rail mount |
Dimensions and weight | |
| Width | 52.5 mm |
| Depth | 54.5 mm |
| Height | 90 mm |
Operating Conditions | |
| Operating Temperature | -30...70 °C |
Standards and Certifications | |
| EMI | EN 61000-3-3, EN 61000-3-2 Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 55024, EN 55032 |
| Safety | UL 508, EN 62368-1 (LVD), UL 62368-1 |
