Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, DIN-Rail mount |
CPU | |
| Processor Installed | Intel Atom E3845 |
Memory | |
| Socket Type | 1xSODIMM 204pin |
| Maximum Memory | 4 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232/422/485 | 6 |
| USB Total | 4 |
| USB 2.0 | 3 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | 6xDB9, 2xRJ45 Ethernet, 4xUSB, DC Input, Display Port |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Linux OS |
Dimensions and weight | |
| Width | 85 mm |
| Height | 140.7 mm |
| Depth | 163 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
