Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Display | |
| Display Type | LED Character |
Analog Input | |
| Total channels of analog input | 1 |
| Number of Bits | 16 Bit |
| Voltage range | +/-15 mV, +/-50 mV, +/-100 mV, +/-500 mV, +/-1 V, +/-2.5 V |
| Current range | -20...+20 mA |
| Sampling rate | 10 Hz |
| Differential channels | 1 |
| Thermocouple | J: -210...+760 °С, K: -270...+1372 °С, T: -270...+400 °С, E: -270...+1000 °С, R: 0...1768 °С, S: 0...1768 °С, B: 0...1820 °С, N: -270...+1300 °С, C: 0...+2320 °С, L: -200...+800 °С, M: -200...+100 °С |
Digital Input | |
| Total channels of digital input | 1 |
| Type | Dry contact |
| Sink/Source | Source |
| Counter capacity | 16 Bit |
| Max frequency | 0.05 kHz |
| Counter | 50Hz, 16 bit |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 3.5~30 V |
| Max. load current | 30 mA |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | DCON slave |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 72 mm |
| Depth | 35 mm |
| Height | 123 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
