Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Display | |
| Display Type | LED Character |
CPU | |
| Processor Installed | 80188 |
| Max CPU frequency | 0.04 GHz |
Memory | |
| SRAM | 512 kB |
Installed drive | |
| Flash Memory Capacity | 0.512 MB |
| EEPROM Memory Capacity | 2 kB |
| Non-volatile NVRAM memory capacity | 31 Byte |
Software | |
| Operating System Installed | Mini OS7 |
| Programming Method | C/C++ |
Digital Input | |
| Total channels of digital input | 1 |
| Type | Dry contact |
Digital Output | |
| Total channels of digital output | 1 |
| Type | Open collector |
| Max. load current | 100 mA |
| Output voltage | 1~30 V |
Interfaces | |
| COM Total | 2 |
| RS-485 | 1 |
| RS-232/485 | 1 |
Industrial Interfaces | |
| CAN Port | 1 |
Supported Protocols | |
| Industrial Protocols | CAN |
Additional Functions | |
| Watchdog timer type | Hardware |
Dimensions and weight | |
| Width | 72 mm |
| Depth | 119 mm |
| Height | 33 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
