Specification
Construction | |
| Construction Chassis | Plastic Chassis |
Digital Input | |
| Total channels of digital input | 4 |
| Sink/Source | Sink |
| Isolation of Digital Input | 3000 V |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | DCON slave |
Expansion Module | |
| Communication interface | Serial Bus |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Dimensions and weight | |
| Width | 30 mm |
| Depth | 115 mm |
| Height | 102 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2 |
