Specification
Construction | |
| Construction Chassis | Plastic Chassis |
Analog Input | |
| Total channels of analog input | 2 |
| Number of Bits | 16 Bit |
| Voltage range | +/-15 mV, +/-50 mV, +/-100 mV, +/-500 mV, +/-1 V, +/-2.5 V |
| Current range | -20...+20 mA |
| Sampling rate | 10 Hz |
| io_tenso_bridge_type | quarter, half, full |
Analog Output | |
| Channels of analog input | 1 |
| DAC Bit Rate | 16 Bit |
| Voltage range | 0...10 V |
Digital Input | |
| Total channels of digital input | 2 |
| Type | Wet contact |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 3.5~50 V |
| Sink/Source | Sink |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 3.5~50 V |
| Max. load current | 700 mA |
Supported Protocols | |
| Industrial Protocols | DCON slave |
Expansion Module | |
| Communication interface | Serial Bus |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
