Specification
Construction | |
| Construction Chassis | Plastic Chassis |
Digital Input | |
| Total channels of digital input | 8 |
| Type | Wet contact |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 3.5~30 V |
| Sink/Source | Sink, Source |
| Counter capacity | 16 Bit |
| Max frequency | 0.1 kHz |
| Counter | 100Hz, 16 bit |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~30 V |
| Max. load current | 700 mA |
Supported Protocols | |
| Industrial Protocols | DCON slave |
Expansion Module | |
| Communication interface | Serial Bus |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
