Specification
Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in |
Analog Input | |
| Total channels of analog input | 16 |
| Number of Bits | 16 Bit |
| Voltage range | +/-1.25 V, +/-2.5 V, +/-5 V, +/-10 V |
| Current range | -20...+20 mA |
| Sampling rate | 250 Hz |
| Differential channels | 8 |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 31 mm |
| Depth | 144 mm |
| Height | 134 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
