Specification
Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in |
Analog Output | |
| Channels of analog input | 4 |
| DAC Bit Rate | 14 Bit |
| Voltage range | +/-10 V |
| Current range | 0...20 mA |
Expansion Module | |
| Communication interface | Parallel Bus |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 31 mm |
| Depth | 144 mm |
| Height | 134 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2 |
