Specification
Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in |
Digital Input | |
| Total channels of digital input | 8 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 4~30 V |
| Sink/Source | Sink, Source |
Expansion Module | |
| Communication interface | Parallel Bus |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 31 mm |
| Depth | 144 mm |
| Height | 134 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2 |
