Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, Wall VESA 100 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i7-3555LE |
| Max CPU frequency | 3.2 GHz |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 8 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel 82579LM 10/100/1000Mbps, Intel PHY WG82579LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 1 |
| RS-422/485 | 3 |
| USB Total | 2 |
| USB v3.x | 2 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 128 GB |
Connectors | |
| Connectors | 4xDB9, DB15 VGA, HDMI, 2xRJ45, 2xUSB, Mic In, Line In, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 0...24 V |
Power Supply | |
| Output Power | 60 W |
Dimensions and weight | |
| Width | 296 mm |
| Height | 214 mm |
| Depth | 71 mm |
Operating Conditions | |
| Operating Temperature | -15...55 °C |
| Vibration | 5Hz~500Hz / 1Grms/3 Axis |
| Shock | 15G. 11ms duration |
