Construction | |
| Construction Chassis | Plastic Chassis |
| Protection Level of Chassis | IP42 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 800x480 Dots |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 500~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | NXP i.MX6 quad-core |
| Socket | CPU onboard |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Interfaces | |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces | |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 8 GB |
| 2nd Storage Capacity | 8 GB |
Extension Slots | |
| SIM Card slots | Yes, 1 |
Additional Functions | |
| Camera Frontside | 5 MP |
| Rear Camera | 5 MP |
| GPS | GPS |
Antenna characteristics | |
| Cellular interfaces | 3G |
| Bluetooth | v3.0 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, 1xReset, Volume Keys, Function Keys |
Connectors | |
| Connectors | 2xUSB, MicroSD card slot, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 36 W |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 1050 mA*h |
Software | |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 247.5 mm |
| Height | 160.2 mm |
| Depth | 30.6 mm |
Operating Conditions | |
| Operating Temperature | -10...70 °C |
| Humidity | 10-90% |
| Vibration | 20 to 1000 Hz @ 3 grms |
| Shock | 11 ms @ 30G |
