Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 5 |
| USB v3.x | 1 |
Connectors | |
| Connectors | DB15 VGA, 2xRJ45 Ethernet, 6xUSB, Mic In, Line In, Line Out, 2xPS/2 Keyboard/Mouse |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 264 mm |
| Height | 57 mm |
| Depth | 192 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
