System Architecture | |
| Form Factor | COM Express Basic |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Xeon D-1518 |
| Max CPU frequency | 2.2 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i210 |
| Total Ethernet | 2 |
| 10 Gbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | SMBus Power Output |
Dimensions and weight | |
| Width | 125 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
