ICE-ULT3-i5

ICE-ULT3-i5

IEI
Ціна за запитом
COM Express Rev 2.1 Mini Size Type 6 Module, Intel Core i5-6300U CPU, DDR4, VGA, LVDS, DDI, GbE, SATAIII, USB 3.0, HD Audio, -20..+65C

Specification

System Architecture

Form FactorCOM Express Compact

Construction

TypeFanless

CPU

Processor InstalledIntel Core i5-6300U
SocketCPU onboard
Max CPU frequency3 GHz
Number of CPU1

Chipset

ChipsetIntel Skylake SoC

Memory

Form-factorDDR4
Socket Type2xSODIMM
Maximum Memory32 GB
AssemblyRemovable

Graphic

Graphic ControllerIntegrated in CPU
InterfacesLVDS, VGA, DDI

Ethernet

Controller TypeIntel i219-LM
Total Ethernet1
10/100/1000 Mbit/s1

Interfaces

COM Total2
RS-2322
USB Total8
USB 2.04
USB v3.x4

Digital Input-Output

Channels of DIO8

Audio

Audio ControllerIntel HD Audio

Additional Functions

Watchdog timer typeSoftware

Dimensions and weight

Width95 mm
Length95 mm

Operating Conditions

Operating Temperature-20...65 °C

Files

Documentation

📄 Datasheet ICE-ULT3
