Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | ST |
Fiber |
| Type of Fibre Optic | multi-mode |
Industrial Interfaces |
| Profibus DP Version | 2 |
Digital Output |
| Total channels of digital output | 1 |
| Type | Signal Relay |
| Contact rating of relay (Form A) | 2A@30V DC |
Supported Protocols |
| Industrial Protocols | Profibus |
LED / Controls |
| LED | READY LED, PWR1, PWR2, PROFIBUS Status LED |
| Setup of Operation Mode | By Switches |
Connectors |
| Connectors | DB9 Female |
System Power Input |
| Input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Dimensions and weight |
| Width | 39 mm |
| Depth | 70 mm |
| Height | 115 mm |
Standards and Certifications |
| Certifications | CE |
| EMI | EN 55022 Class A, EN 55024, FCC Part 15 Subpart B Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Explosion safety | IECEx, ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 508, EN 60950-1 |
