Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Bay Trail |
| Processor Installed | Intel Atom E3827 |
| Max CPU frequency | 1.75 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 4 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232/422/485 | 4 |
| USB Total | 2 |
| USB 2.0 | 2 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Antenna characteristics | |
| Cellular interfaces | 3G (Optional) |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DB15 VGA, 2xRJ45 Ethernet, 2xUSB, DC input (terminal block), DB9 DIO |
System Power Input | |
| Input Voltage DC | 12...24 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Linux OS |
Dimensions and weight | |
| Width | 48 mm |
| Height | 155 mm |
| Depth | 110 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Vibration | 2G. 10...150Hz. amplitude 0.35 mm |
| Shock | Operating. 25G. half-sine. duration 11 ms |
Standards and Certifications | |
| Certifications | CE/FCC |
| Safety | EN 60950 |
