Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Braswell |
| Processor Installed | Intel Celeron N3160 |
| Max CPU frequency | 2.24 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Digital Input | |
| Isolation DIO | No |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, 2xRJ45 Ethernet, 4xUSB, DC input (terminal block), 3xSMA, DB9 DIO |
System Power Input | |
| Input Voltage DC | 12...24 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 48 mm |
| Height | 155 mm |
| Depth | 110 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | 2g @ 5 ~ 500Hz. amplitude 0.35 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
