Ethernet |
| 10/100/1000 Mbit/s | 24 |
| 10 Gbit/s | 4 |
| SFP 100/1000 Mbit Ports | 4 |
| ethernet_poe_1000mbit | 24 |
| ethernet_poe_standard | 802_3at |
Interfaces |
| RS-232 | 1 |
Switch Properties |
| Switch Level | Layer 2 |
Supported Protocols |
| Industrial Protocols | Modbus TCP |
| Managment Protocols | SNMPv1/v2c/v3, HTTP, Telnet, TFTP |
| Security Protocols | SSH, SSL |
| IEEE Standard | IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 44 mm |
| Depth | 280 mm |
| Height | 440 mm |
Operating Conditions |
| Operating Temperature | -10...60 °C |
Standards and Certifications |
| Certifications | CE |
| EMI | FCC Part 15, EN 61000-6-4 |
| EMS | IEC 61000-6-2, EN 55024, EN 61000-6-4, EN 55032 |
| Rolling Stock | EN 50121-4 |
| Safety | UL 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-6 |
