Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | 80186 |
| Max CPU frequency | 0.08 GHz |
Expansion Module | |
| Quantity of Slots | 8 |
| Supported Module | F-8000 series |
Ethernet | |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 374 mm |
| Depth | 100 mm |
| Height | 132 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
