Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in, Panel, Wall VESA 100, Wall VESA 75 |
Display | |
| Display Type | LCD |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1000~1 |
| Input Interface | VGA, DVI-D |
LED / Controls | |
| Controls | On/Off, KeyPad |
Connectors | |
| Connectors | DVI-D, DB15 VGA, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
| Vibration | 2.16Grms sine. 5~500Hz. 1hr/axis |
Dimensions and weight | |
| Width | 438 mm |
| Height | 369.7 mm |
| Depth | 34.3 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| Safety | CCC |
