Construction | |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in, Panel, Wall, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 800x480 Dots |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 500~1 |
| Input Interface | VGA, DVI |
Touch Screen | |
| Touch Screen Type | Resistive |
| Interface | USB |
LED / Controls | |
| Controls | KeyPad |
Connectors | |
| Connectors | DVI, DB15 VGA, DC Input, USB type B |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 8 W |
Power Supply | |
| Type of Power Supply | DC-DC |
| Supported Types of Power Supply | External power adapter AC/DC |
| Input Voltage DC | 12...12 V |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | 5-500Hz. 0.026G/Hz. 2.16 Grms. X.Y.Z. 1hr per axis |
Dimensions and weight | |
| Width | 190 mm |
| Height | 142 mm |
| Depth | 36.5 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
